NXF ASTM UNSS31603 316L/00Cr17Ni14Mo2/1.4404 DN 15-1200 Class150-Class2500 Stainless Steel 316L Threaded Coupling

Product Categories

NXF GROUP (New XiFei (SuZhou) Business Co.,Ltd)

Contact Now

1.4404 DN 15-1200 Class150-Class2500 Stainless Steel 316L Threaded Coupling

Ask Lasest Price
Brand Name :	NXF
Certification :	ISO CE
Price :	Negotiation
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	300ton/month
Delivery Time :	5-8 work days
Model Number :	DN15-1200
MOQ :	1 Piece

Add to Cart

Product Details
Company Profile

NXF ASTM UNSS31603 316L/00Cr17Ni14Mo2/1.4404 DN 15-1200 Class150-Class2500 Stainless Steel 316L Threaded Coupling

Product Description

Grade 316/316L is molybdenum-bearing austenitic stainless steel. The higher nickel and molybdenum content in this grade allows it to demonstrate better overall corrosion resistant properties than 304, especially with regard to pitting and crevice corrosion in chloride environments. In addition, Alloy 316/ 316L provides excellent elevated temperature tensile, creep and stress-rupture strengths, as well as outstanding formability and weldability. 316L is the lower carbon version of 316 and is immune from sensitization; therefore, it is very frequently used in heavy gauge welded components.

Threaded double-joint pipe clamp is an accessory used for pipe connection. It is usually formed by die-forging blanks of round steel or steel ingots, and then machined into shape by lathe. The connection form of the threaded double-port pipe clamp is a threaded connection, which can be connected to pipes or other pipe fittings through threads. The main manufacturing standards of this type of pipe clamp include ASME B16.11, GB/T7306, 12716, 14383, MSS SP-79, 83, 95, 97JIS B0203, B2316, etc. The varieties of threaded double-joint pipe clamps include equal-diameter and different-diameter pipe clamps, and the double-joint pipe clamps of different diameters are also divided into concentric and eccentric. They can be widely used in pipes of different diameters,including single-way, three-way, four-way, etc., and can also be used in water meters and valves.

316L Threaded Coupling Drawing

NXF ASTM UNSS31603 316L/00Cr17Ni14Mo2/1.4404 DN 15-1200 Class150-Class2500 Stainless Steel 316L Threaded Coupling

316L of Chemical composition and mechanical properties

Specification

Product name	316L Threaded Coupling
Material	SS316L
Size	1/2"-48" DN15-DN1200
Pressure	Class150-Class2500
Standard	ANSI JIS DIN ASME
MOQ	1 Piece
Connection method	Threaded
Application	Industry
Packing	Standard Seaworthy Packing
Brand	NXF

Packing & Delivery

NXF ASTM UNSS31603 316L/00Cr17Ni14Mo2/1.4404 DN 15-1200 Class150-Class2500 Stainless Steel 316L Threaded Coupling

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Company Profile

NXF ASTM UNSS31603 316L/00Cr17Ni14Mo2/1.4404 DN 15-1200 Class150-Class2500 Stainless Steel 316L Threaded Coupling

New XiFei (SuZhou) Business Co.,Ltd is one of the leading and most respected manufacturers in China. Our products include metals,machinery, containers, construction materials, mechanical products, electrical systems, and medical accessories. Established in1980, XIFEI has been working diligently ever since to embrace the needs of our global customer base.We work to ensure absolute customer satisfaction. Our team has dedicated itself to perfecting our three core components, "Service, Management and Craftsmanship."

Our advantage:3S Service(Small Quantity/Short Time/Special Material)

Application

NXF ASTM UNSS31603 316L/00Cr17Ni14Mo2/1.4404 DN 15-1200 Class150-Class2500 Stainless Steel 316L Threaded Coupling

Certifications
